| Part No. | Dia. | F (mm) | G (mm) | H (mm) |
| LCSS-06G | 3/16" | 4.75 - 4.98 | 7.72 - 7.90 | 5.59 - 6.60 |
LCSS-08G
| 1/4" | 6.50 - 6.73 | 10.21 - 10.39 | 7.37 - 8.13 |
LCSS-10G
| 5/16" | 7.72 - 7.92 | 12.32 - 12.54 | 8.89 - 9.65 |
LCSS-12G
| 3/8" | 9.52 - 9.78 | 14.99 - 15.24 | 10.92 - 11.68 |
LCSS-16G
| 1/2" |
13.08 - 13.72 |
19.43 - 20.32 |
15.49 - 16.38 |
LCSS-20G
| 5/8" |
16.51 - 16.89 |
24.64 - 25.65 |
21.46 - 22.22 |
LCSS-24G
| 3/4" |
19.68 - 20.07 |
29.59 - 29.97 |
23.62 - 24.38 |
LCSS-28G
| 7/8" |
23.11 - 23.75 |
34.16 - 34.92 |
27.51 - 28.27 |
LCSS-32G
| 1" |
26.16 - 26.67 |
39.37 - 40.01 |
31.37 - 32.51 |
LCSS-36G
| 1-1/8" | 29.21 - 29.97
| 44.20 - 44.96
| 35.31 - 36.58
|
LCSS-44G
| 1-3/8" | 35.79 - 36.04 | 54.53 - 54.79 | 44.15 - 44.75 |
1. High-Performance Design for Structural Stability
The PI Collars-Standard is crafted to deliver exceptional performance in fastening applications requiring structural stability. Engineered with a precise fit, these collars distribute load evenly across PI lockbolt assemblies, ensuring a secure and vibration-resistant joint. They are widely used in bridges, industrial equipment, and transport vehicles, where reliability is paramount. At Pankaj International, we focus on designing products that align with the exacting needs of modern industries.
2. Material Excellence and Corrosion Resistance
Built with premium-grade materials, the PI Collars Standard offers superior resistance to wear, corrosion, and environmental challenges. Whether in marine environments, aerospace structures, or railway tracks, these collars maintain their integrity over extended periods. With options in stainless steel, zinc coatings, and weather-resistant finishes, our collars are designed to perform under extreme conditions.
3. Seamless Compatibility with PI Lockbolts
The Pi Collars-Standard pairs perfectly with structural PI lockbolts, ensuring an efficient and reliable assembly process. Designed for use with a wide range of PI lockbolt installation tools, these collars simplify installation while maximizing strength and durability. Whether you're working on industrial machinery, construction steelwork, or heavy-duty applications, our collars ensure precision and ease.
4. Compliance with International Standards
At Pankaj International, we adhere to globally recognized standards such as ISO, BS , DIN ANSI & JIS specifications to guarantee the highest level of quality. Each Collar-Standard undergoes rigorous testing for performance under demanding conditions, ensuring reliability in critical applications. By aligning with industry benchmarks, we deliver fasteners trusted by professionals worldwide.
5. Technical Drawings and Customization Options
For professionals seeking detailed specifications, we offer complete technical drawings and data sheets for the PI Collars-Standard. These resources include dimensions, weight tolerances, and torque values, simplifying product selection for specialized projects. Contact Pankaj International for customized solutions tailored to your unique fastening needs.
6. Why Choose Pankaj International for Collars?
As the best fastener manufacturer in India, Pankaj International combines expertise, precision, and innovation to create products that exceed industry standards. Our Collars-Standard represent our commitment to delivering high-quality fasteners that meet the needs of global clients in construction, marine, and aerospace sectors.
