| Thread | a | b | c | s1 |
| M10 x 1.0 | 19 | 5 | 6 | 14 |
| M12 x 1.5 | 28 | 6 | 6 | 17 |
| M14 x 1.5 | 32 | 8 | 7 | 19 |
| M16 x 1.5 | 39 | 9 | 7.5 | 22 |
| M18 x 1.5 | 45 | 11 | 8 | 24 |
| M22 x 1.5 | 19 | 14 | 9 | 27 |
| M26 x 1.5 | 41 | 18 | 10 | 32 |
| M30 x 2.0 | 32 | 22 | 11 | 38 |
Introduction to Banjo Bolts
Banjo Bolts are highly specialized fasteners that serve a crucial role in creating secure and leak-free connections in hydraulic and fluid systems. Characterized by a hollow, threaded body and unique banjo-shaped fittings, these bolts allow fluid to pass through the bolt itself while providing a robust mechanical connection. This innovative design makes them indispensable in automotive braking systems, fuel lines, and high-pressure hydraulic systems where efficiency and reliability are paramount.
Key Features of Banjo Bolts
The distinct features of Banjo Bolts are what make them stand out in various applications:
- Hollow Structure: The bolt’s hollow shaft allows fluid to flow freely, making it ideal for high-pressure hydraulic systems.
- Precision Machining: Engineered with tight tolerances to ensure proper sealing and prevent fluid leakage.
- Corrosion Resistance: Available in stainless steel and galvanized finishes to withstand harsh environmental conditions and chemical exposure.
- Versatile Compatibility: Designed to fit with a wide range of hydraulic and fuel line systems across multiple industries.
- Durability: Built to handle extreme pressures and temperatures, maintaining performance over extended periods.
Applications of Banjo Bolts
The versatility of Banjo Bolts allows them to be used across various industries:
- Automotive Industry: Integral to brake lines, fuel injection systems, and turbochargers, providing reliable performance under extreme conditions.
- Hydraulics: Essential for connecting hoses in machinery, ensuring smooth and uninterrupted fluid flow.
- Aerospace Engineering: Used in high-performance fluid transfer systems due to their lightweight and efficient design.
- Marine Applications: Suitable for corrosive environments, ensuring long-lasting performance in boats and ships.
Material Options and Coatings
Pankaj International offers Banjo Bolts in a variety of materials to suit different operational needs:
- Stainless Steel: Preferred for its strength, corrosion resistance, and aesthetic appeal.
- Carbon Steel: Cost-effective yet durable, suitable for standard applications.
- Galvanized Coatings: Provide an additional layer of corrosion resistance, making them ideal for outdoor and marine environments.
- Zinc Coatings: Enhance the bolt’s lifespan by protecting it against oxidation and wear.
Banjo Bolt Tables and Drawings
To simplify the selection process, we provide comprehensive technical tables and drawings for our Banjo Bolts. These include:-
- Dimensional Specifications: Thread sizes, lengths, and fitting diameters.
- Material Grades: Options tailored for specific applications.
Torque Requirements: Ensuring proper installation and optimal performance.
The drawings and charts make it easy for engineers and technicians to identify the right product for their specific needs, whether it’s a complex hydraulic system or a high-performance automotive setup.
Benefits of Using Banjo Bolts
Choosing Banjo Bolts over traditional fasteners offers several advantages:
- Leak-Proof Connections: Ensures reliable sealing in fluid systems, preventing costly leaks or system failures.
- Space-Saving Design: The compact and efficient design accommodates tight spaces, often found in automotive and industrial machinery.
- Enhanced Efficiency: Reduces fluid transfer restrictions, ensuring smoother system operations.
- Easy Installation and Maintenance: Allows for straightforward assembly and disassembly, reducing downtime during repairs.
Why Pankaj International for Banjo Bolts?
At Pankaj International, we take pride in being one of the best fastener manufacturers in India, delivering products that meet the highest quality standards. Our Banjo Bolts are crafted with precision, ensuring optimal performance across diverse industries. We also cater to global markets, offering customized solutions for businesses worldwide. In addition to Banjo Bolts, we specialize in lock bolts and collars, providing a comprehensive range of fasteners to meet every industrial requirement. With a focus on innovation and quality, we ensure our products remain at the forefront of the fastener manufacturing industry.
