| Dimension |
Dk |
k |
a |
g |
b |
| M6 |
12.55 |
4 |
90 |
2.5 |
18 |
| M8 |
16.55 |
5 |
90 |
3.0 |
22 |
| M10 |
19.65 |
5.5 |
90 |
3.2 |
26 |
| M12 |
24.65 |
7 |
90 |
3.6 |
30 |
| M16 |
32.80 |
9 |
90 |
4.2 |
38 |
| M20 |
32.80 |
11.5 |
60 |
5.4 |
46 |
| M24 |
38.80 |
13 |
60 |
6.6 |
54 |
What is a Nib Bolt?
A Nib Bolt is a specialized type of fastener that features small protrusions, or "nibs," on its surface, enhancing its grip within the assembly. These nibs increase the bolt's holding power, making it particularly suitable for applications requiring reliable and vibration-resistant fastening. Widely used in structural frameworks, heavy machinery, and construction projects, Nib Bolts are known for their precision engineering and robust performance.
Features of Nib Bolts
Nib Bolts are engineered to offer unique benefits that set them apart from standard fasteners:-
- Enhanced Grip: The nibs on the bolt surface improve the connection by providing added friction, ensuring a secure fit.
- Durability: Manufactured from high-grade materials, they are designed to withstand extreme conditions, including heavy loads and high vibrations.
- Corrosion Resistance: Coated with galvanized or zinc metal finishes, Nib Bolts are protected against rust and corrosion, ensuring longevity.
- Precision: Available in a variety of sizes and dimensions, with detailed Nib Bolt tables for easy selection.
Applications of Nib Bolts
The versatility of Nib Bolts makes them indispensable in various industries:-
- Construction: Used in bridges, buildings, and other structural projects where strength and stability are critical.
- Automotive: Perfect for fastening components in vehicles and heavy equipment.
- Industrial Machinery: Ensures secure assembly of machines operating under high stress and vibration.
- Railways: Used in fastening systems where durability and stability are paramount.
Technical Specifications and Nib Bolt Table
At Pankaj International, we provide a detailed Nib Bolt table that includes all the necessary specifications to meet diverse industrial needs. This table covers:
- Bolt Length: Ranging from small to large sizes to fit varying assembly requirements.
- Thread Pitch: Ensuring smooth and precise fastening.
- Head Diameter: Standardized dimensions for easy integration into pre-existing systems.
- Material Grades: Options include stainless steel, carbon steel, and alloy steel for specialized applications.
These tables simplify the selection process for engineers and contractors, ensuring accurate choices for every project.
Advantages of Using Nib Bolts
Choosing Nib Bolts from Pankaj International comes with several advantages:-
- Reliable Performance: The nibbed design ensures a secure and vibration-resistant fit.
- Custom Options: Available in a wide range of sizes and materials to suit specific industrial requirements.
- Ease of Use: Standardized specifications make installation straightforward, reducing assembly time.
- Corrosion Protection: Coatings like galvanized and zinc metal extend the bolt’s lifespan in harsh environments.
Why Pankaj International for Nib Bolts?
As one of the best fastener manufacturers in India, Pankaj International takes pride in delivering top-quality products like Nib Bolts that meet and exceed international standards. With years of expertise, we offer fasteners designed for precision, strength, and durability. Our extensive catalog includes detailed Nib Bolt size charts, ensuring that our clients find the exact specifications they need. Our Nib Bolts are crafted using advanced manufacturing processes, ensuring consistency in performance. Whether you are sourcing fasteners for a small project or a large-scale industrial application, our team is committed to providing solutions tailored to your needs. From stainless steel bolts and nuts to locking bolts and csk screws, we cover the entire spectrum of fastener products.
