Hexagonal Socket Head Cap Screws Weight Chart
HEXAGONAL SOCKET HEAD CAP SCREWS
TO IS 2269/2006 ISO 4762:2004
Weights are in Kilograms per 100 pieces unless otherwise specified. All weights are approximations and strictly informative.
Dia
Length |
M2 | M3 | M4 | M5 | M6 | M8 | M10 | M12 | M14 | M16 | M20 | M24 | M30 | M36 | M42 | M48 | M56 | M64 |
| 6 | 0.0215 | 0.071 | 0.15 | | | | | | | | | | | | | | |
|
| 8 | 0.0255 | 0.08 | 0.165 | 0.245 | | | | | | | | | | | | | |
|
| 10 | 0.0295 | 0.088 | 0.18 | 0.27 | 0.47 | | | | | | | | | | | | |
|
| 12 | 0.0355 | 0.096 | 0.195 | 0.295 | 0.507 | 1.09 | | | | | | | | | | | |
|
| 16 | 0.0415 | 0.116 | 0.225 | 0.345 | 0.575 | 1.21 | 2.09 | | | | | | | | | | |
|
| 20 | 0.0495 | 0.136 | 0.265 | 0.401 | 0.653 | 1.34 | 2.29 | 3.21 | | | | | | | | | |
|
| 25 | | 0.161 | 0.315 | 0.478 | 0.759 | 1.5 | 2.54 | 3.57 | 4.8 | 7.13 | | | | | | | |
|
| 30 | | 0.186 | 0.365 | 0.555 | 0.83 | 1.69 | 2.79 | 3.93 | 5.3 | 7.78 | 12.8 | | | | | | |
|
| 35 | | | 0.415 | 0.632 | 0.991 | 1.89 | 3.04 | 4.29 | 5.8 | 8.44 | 13.9 | | | | | | |
|
| 40 | | | 0.465 | 0.709 | 1.1 | 2.09 | 3.29 | 4.65 | 6.3 | 9.1 | 15 | 27 | | | | | |
|
| 45 | | | | 0.786 | 1.21 | 2.29 | 3.61 | 5.01 | 6.8 | 9.76 | 16.1 | 28.5 | 50 | | | | |
|
| 50 | | | | 0.863 | 1.32 | 2.49 | 3.93 | 5.45 | 7.3 | 10.6 | 17.2 | 30 | 52.7 | | | | |
|
| 55 |
|
|
|
| 1.43 | 2.69 | 4.25 | 5.89 | 7.8 | 11.4 | 18.3 | 31.6 | 55.4 | 87 |
|
|
|
|
| 60 |
|
|
|
| 1.54 | 2.89 | 4.57 | 6.34 | 8.4 | 12.2 | 19.4 | 33 | 58.1 | 91 | 137 |
|
|
|
| 65 |
|
|
|
|
| 3.1 | 4.89 | 6.78 | 9 | 13 | 20.5 | 34.5 | 60.8 | 95 | 142 |
|
|
|
| 70 |
|
|
|
|
| 3.3 | 5.21 | 7.13 | 9.6 | 13.8 | 21.6 | 36.3 | 63.5 | 99 | 147 | 204 |
|
|
| 80 |
|
|
|
|
| 3.7 | 5.85 | 8.02 | 10.8 | 15.4 | 24.1 | 39.9 | 69 | 107 | 158 | 218 | 334 |
|
| 90 |
|
|
|
|
|
| 6.49 | 8.91 | 12 | 17 | 26.6 | 43.5 | 74.5 | 115 | 168 | 232 | 353 | 522 |
| 100 |
|
|
|
|
|
| 7.12 | 9.8 | 13.2 | 18.6 | 29.1 | 47.1 | 80 | 123 | 179 | 246 | 372 | 547 |
| 110 |
|
|
|
|
|
|
| 10.7 | 14.4 | 20.2 | 31.6 | 50.7 | 85.5 | 131 | 189 | 260 | 392 | 573 |
| 120 |
|
|
|
|
|
|
| 11.6 | 15.6 | 21.8 | 34.1 | 54.3 | 91 | 139 | 200 | 274 | 411 | 598 |
| 130 |
|
|
|
|
|
|
|
| 16.8 | 23.4 | 36.6 | 57.9 | 96.5 | 147 | 210 | 288 | 430 | 623 |
| 140 |
|
|
|
|
|
|
|
| 18 | 25 | 39/1 | 61.5 | 102 | 155 | 221 | 302 | 449 | 649 |
| 150 |
|
|
|
|
|
|
|
|
| 26.6 | 41.6 | 65.1 | 108 | 163 | 232 | 316 | 468 | 674 |
| 160 |
|
|
|
|
|
|
|
|
| 28.2 | 44.1 | 68.7 | 113 | 171 | 242 | 330 | 488 | 690 |
| 180 |
|
|
|
|
|
|
|
|
|
| 49.1 | 75.9 | 124 | 187 | 264 | 359 | 527 | 725 |
| 200 |
|
|
|
|
|
|
|
|
|
| 54.1 | 83.1 | 135 | 203 | 286 | 387 | 565 | 775 |
| 220 |
|
|
|
|
|
|
|
|
|
|
| 90.3 | 146 | 219 | 308 | 415 | 604 | 825 |
| 240 |
|
|
|
|
|
|
|
|
|
|
| 97.5 | 157 | 225 | 330 | 443 | 642 | 875 |
| 260 |
|
|
|
|
|
|
|
|
|
|
|
| 168 | 241 | 352 | 471 | 681 | 926 |
| 280 |
|
|
|
|
|
|
|
|
|
|
|
| 179 | 257 | 374 | 499 | 720 | 976 |
| 300 |
|
|
|
|
|
|
|
|
|
|
|
| 190 | 273 | 396 | 527 | 758 | 1030 |
