Round Head Rivets Weight Chart
ROUND HEAD RIVETS
Weights are in Kilograms per 100 pieces unless otherwise specified. All weights are approximations and strictly informative.
| LENGTH |
D I A M E T E R |
| 1/4" |
5/16" |
3/8" |
7/16" |
1/2" |
5/8" |
3/4" |
7/8" |
1" |
| 1/2" | 0.570 | 0.961 | 1.555 | | | | | | |
| 5/8" | 0.661 | 1.079 | 1.747 | | | | | | |
| 3/4" | 0.727 | 1.228 | 1.933 | 2.841 | 3.623 | | | | |
| 7/8" | 0.800 | 1.323 | 2.096 | 3.064 | 3.779 | 6.305 | | | |
| 1" | 0.866 | 1.437 | 2.232 | 3.324 | 4.078 | 6.993 | 11.236 | | |
| 1.1/4" | 1.034 | 1.680 | 2.587 | 3.837 | 4.677 | 7.949 | 12.821 | 18.116 | |
| 1.3/8" | 1.103 | 1.801 | 2.789 | 4.065 | 5.040 | 8.757 | 13.369 | 18.939 | |
| 1.1/2" | 1.180 | 1.939 | 3.025 | 4.322 | 5.274 | 9.009 | 13.928 | 19.841 | 25.773 |
| 1.5/8" | | | 3.163 | 4.496 | 5.669 | 9.452 | 14.663 | 20.833 | 27.174 |
| 1.3/4" | | | 3.316 | 4.686 | 5.945 | 10.183 | 15.480 | 21.834 | 28.090 |
| 1.7/8" | | | 3.494 | 4.941 | 6.305 | 10.417 | 16.234 | 22.727 | 29.240 |
| 2" | | | 3.693 | 5.225 | 6.711 | 10.753 | 16.779 | 23.474 | 30.675 |
| 2.1/8" | | | | | 6.935 | 11.186 | 17.182 | 24.390 | 31.847 |
| 2.1/4" | | | | | 7.564 | 11.962 | 17.921 | 25.641 | 32.895 |
| 2.3/8" | | | | | 7.752 | 12.315 | 18.587 | 26.738 | 34.247 |
| 2.1/2" | | | | | 7.862 | 12.788 | 19.305 | 27.473 | 34.965 |
| 2.5/8" | | | | | 8.197 | 13.405 | 19.920 | 28.249 | 35.971 |
| 2.3/4" | | | | | 8.361 | 13.661 | 20.576 | 29.070 | 37.313 |
| 2.7/8" | | | | | 8.772 | 14.368 | 21.186 | 30.303 | 38.462 |
| 3" | | | | | 9.025 | 14.663 | 21.930 | 31.646 | 39.683 |
| 3.1/8" | | | | | | | 22.831 | 32.468 | 40.984 |
| 3.1/4" | | | | | | | 23.585 | 33.333 | 42.373 |
| 3.3/8" | | | | | | | 24.272 | 34.483 | 43.478 |
| 3.1/2" | | | | | | | 24.876 | 35.211 | 44.643 |
| 3.3/4" | | | | | | | | 37.037 | 47.170 |
| 4" | | | | | | | | 38.760 | 50.000 |
