Square Head Bolts Weight Chart
Weight Chart for DIN 479 Square Head Bolts
Weights are in Kilograms per 100 pieces unless otherwise specified. All weights are approximations and strictly informative.
Dia
Length |
M5 |
M6 |
M8 |
M10 |
M12 |
M16 |
M20 |
M24 |
| 8 | 0.26 | 0.30 | – | – | – | – | – | – |
| 10 | 0.28 | 0.34 | 0.72 | – | – | – | – | – |
| 16 | 0.36 | 0.44 | 0.90 | 1.55 | – | – | – | – |
| 20 | 0.40 | 0.51 | 1.02 | 1.74 | 3.08 | – | – | – |
| 25 | 0.47 | 0.60 | 1.17 | 1.98 | 3.44 | – | – | – |
| 30 | 0.53 | 0.68 | 1.33 | 2.23 | 3.80 | – | – | – |
| 35 | 0.59 | 0.77 | 1.49 | 2.48 | 4.16 | – | – | – |
| 40 | 0.65 | 0.86 | 1.64 | 2.73 | 4.52 | 8.76 | – | – |
| 45 | – | 0.94 | 1.80 | 2.97 | 4.88 | 9.43 | – | – |
| 50 | – | – | 1.95 | 3.22 | 5.24 | 10.1 | 17.6 | – |
| 55 | – | – | 2.11 | 3.47 | 5.60 | 10.7 | 18.6 | 2.59 |
| 60 | – | – | – | 3.72 | 5.96 | 11.4 | 19.7 | 2.73 |
| 70 | – | – | – | – | 6.68 | 12.7 | 21.7 | 3.03 |
| 80 | – | – | – | – | 7.40 | 14.0 | 23.8 | 3.33 |
| 90 | – | – | – | – | 8.12 | 15.3 | 25.8 | 3.62 |
| 100 | – | – | – | – | – | 16.7 | 27.9 | 3.92 |
| 110 | – | – | – | – | – | 18.0 | 29.9 | 4.21 |
| 120 | – | – | – | – | – | 19.3 | 32.0 | 4.51 |
| 140 | – | – | – | – | – | – | 36.1 | 5.10 |
