Screw Weight Chart

HEX SCREW (FULL THREAD)

M2 TO M18

MM THREADS AS PER IS 1363/67

Weights are in Kilograms per 100 pieces unless otherwise specified. All weights are approximations and strictly informative.

Length Dia	M2	M3	M4	M5	M6	M7	M8	M10	M12	M14	M16	M18
3mm	0.031
4mm	0.032	0.081
5mm	0.034	0.086	0.194
6mm	0.036	0.09	0.201	0.329	0.572	0.837
8mm	0.04	0.099	0.217	0.349	0.606	0.887	1.338
10mm	0.044	0.108	0.232	0.374	0.64	0.937	1.392
12mm	0.047	0.117	0.248	0.398	0.674	0.986	1.462	2.943	4.337
16mm	0.053	0.133	0.278	0.448	0.743	1.08	1.593	3.143	4.617
20mm		0.151	0.309	0.498	0.812	1.185	1.712	3.342	4.897
25mm		0.173	0.348	0.56	0.897	1.304	1.873	3.595	5.258	7.716	10.121	14.124
30mm			0.387	0.622	0.983	1.435	2.033	3.843	5.618	8.21	10.799	15.015
35mm			0.425	0.684	1.069	1.555	2.194	4.095	5.981	8.711	11.468	15.823
40mm			0.464	0.746	1.155	1.685	2.354	4.344	6.345	9.208	12.136	16.611
45mm			0.502	0.81	1.243	1.805	2.514	4.596	6.702	9.728	12.853	17.422
50mm			0.541	0.87	1.333	1.935	2.664	4.85	7.052	10.225	13.441	18.248
55mm			0.58	0.932	1.422	2.056	2.825	5.097	7.418	10.707	14.124	19.157
60mm			0.618	0.994	1.502	2.176	2.983	5.359	7.776	11.211	14.837	19.92
65mm			0.657	1.056	1.593	2.305	3.145	5.612	8.143	11.71	15.432	20.747
70mm			0.696	1.121	1.673	2.426	3.305	5.855	8.503	12.225	16.129	21.552
75mm				1.181	1.763	2.556	3.465	6.112	8.865	12.626	16.892	22.422
80mm				1.242	1.853	2.677	3.626	6.361	9.225	13.158	17.544	23.256
85mm					1.933	2.806	3.785	6.614	9.579	13.661	18.182	24.038
90mm					2.023	2.926	3.946	6.868	9.94	14.164	18.868	24.876
100mm					2.194	3.177	4.255	7.364	10.661	15.152	20.161	26.455
110mm					2.361		4.579	7.886	11.39	16.181	21.645	28.249
120mm					2.734		4.95	8.375	12.136	17.182	22.936	29.94
130mm					2.865		5.297	8.881	12.821	18.182	24.155	31.646
140mm					3.012		5.593	9.381	13.514	19.231	25.641	33.333
150mm					3.175		5.869	9.881	14.245	20.243	27.027	34.722
160mm								10.04	14.62		28.571	36.496
170mm								10.395	15.528		29.94	38.168
180mm								11.261	16.34		30.864	39.683
190mm									17.007		32.258	41.667
200mm								12.165	17.794		33.113	43.103
225mm									19.305		36.765
250mm								14.749	21.645		40

HEX SCREW (FULL THREAD)

M20 TO M52

MM THREADS AS PER IS 1363/67

Weights are in Kilograms per 100 pieces unless otherwise specified. All weights are approximations and strictly informative.

Length Dia	M20	M22	M24	M27	M30	M33	M36	M39	M42	M45	M48	M52
25mm	18.727
30mm	19.763
35mm	20.833	25.381
40mm	21.834	26.596	34.965
45mm	22.831	27.933	36.496
50mm	24.038	29.24	38.168	53.763	72.464	92.593
55mm	25.000	30.675	39.370	56.180	74.627	96.154
60mm	26.042	31.847	40.984	57.471	76.923	98.039	125	161.29	185.185		277.778
65mm	27.027	33.113	42.735	60.241	79.365	102.041	131.579	161.29	192.308	238.095		357.143
70mm	28.090	34.483	44.248	61.728	81.967	104.167	135.135	166.667			294.118
75mm	29.070	35.714	45.872	64.103	84.746	108.696	138.889	178.571	200	250
80mm	30.303	37.037	47.170	65.789	87.719	111.111	142.857	178.571
85mm	31.250	38.168	48.544	67.568	89.286	113.636	147.059	185.185	208.333	263.158	312.5	384.615
90mm	32.258	39.683	50.000	69.444	92.593	116.279	151.515	192.308	217.391
100mm	34.483	42.373	53.191	73.529	96.154	121.951	156.25	200	227.273	277.778	333.333	416.667
110mm	36.496	45.045	56.180	78.125	102.041	128.205	166.667	208.333	238.095	294.118
120mm	38.462	47.619	59.524	81.967	106.383	135.135	172.414	208.333	250		357.143
130mm	40.984	50.000	62.500	86.207	111.111	142.857	178.571	227.273		312.5	384.615	454.545
140mm	42.735	52.632	65.789	89.286	116.279	147.059	185.185	238.095	263.158	333.333
150mm	45.045	55.556	68.493	94.340	121.951	151.515	192.308	250	277.778
160mm	47.170	57.471	71.429	98.039	128.205	161.290	200	250			416.667	500
170mm	49.020	60.241	74.627	102.041	131.579	166.667	208.333	263.158	294.118	357.143
180mm	51.020	62.500	79.365	106.383	135.135	178.571	217.391	263.158				555.556
190mm	53.191	65.789	80.645	111.111	142.857	178.571	227.273	277.778	312.500
200mm	54.945	68.493	84.746	113.636	147.059	185.185	227.273	294.118	333.333	384.615	454.545	625
225mm	60.241		92.593		156.250
250mm	65.789		100.000		172.414
300mm	78.125		113.636		192.308

Weight Chart for DIN 933 Hex Screws

Weights are in Kilograms per 100 pieces unless otherwise specified. All weights are approximations and strictly informative.

Length Dia	M3	M4	M5	M6	M7	M8	M10	M12	M14	M16	M18	M20	M22	M24	M30	M36	M48
4	0.048
5	0.053	0.126
6	0.057	0.133	0.218	0.34
7	0.061	0.141	0.228	0.357	0.56
8	0.066	0.149	0.238	0.374	0.585	0.85	1.52
10	0.075	0.164	.0263	0.408	0.635	0.91	1.62	2.33	3.80
12	0.084	0.180	0.287	0.442	0.685	0.98	1.72	2.50	4.00	5.29
14	0.092	0.195	0.312	0.476	0.735	1.05	1.82	2.64	4.20	5.56
16	0.1	0.210	0.337	0.511	0.785	1.11	1.92	2.77	4.40	5.83	8.20	10.5	13.3	17.3
18	0.109	0.250	0.362	0.545	0.835	1.17	2.02	2.91	4.60	6.09	8.4.9	11.0	13.7	17.8
20	0.118	0.241	0.387	0.580	0.885	1.23	2.12	3.10	4.80	6.35	8.72	11.4	14.3	18.4
22	0.127	0.256	0.412	0.615	0.935	1.29	2.20	3.30	5.00	6.62	9.22	11.9	14.8	19.0
25	0.140	0.280	0.449	0.665	1.00	1.39	2.37	3.41	5.30	7.02	9.58	12.4	15.5	19.9
28	0.152	0.304	0.486	0.715	1.07	1.49	2.52	3.62	5.59	7.42	10.0.	12.9	16.1	20.0
30	0.161	0.319	0.511	0.751	1.13	1.55	2.62	3.77	5.79	7.69	10.4.	13.4	16.8	21.4
35		0.357	0.573	0.873	1.25	1.71	2.87	4.13	6.29	8.35	11.2.	14.5	18.1	22.9	42.4	67.0
40		0.396	0.635	0.923	1.38	1.87	3.12	4.49	6.79	9.02	12.0	15.5	19.3	24.4	44.8	71.4	15.9
45		0.434	0.699	1.01	1.50	2.03	3.37	4.85	7.29	9.71	12.8	16.5	20.6	25.9	47.2	74.8	16.5
50		0.473	0.759	1.1	1.63	2.18	3.62	5.20	7.79	10.3	13.6	17.6	21.9	27.4	49.6	78.3	17.1
55		0.512	0.821	1.19	1.75	2.34	3.87	5.56	8.28	11.0	14.5	18.6	23.2	28.9	51.9	81.7	17.7
60		0.550	0.883	1.27	1.87	2.50	4.13	5.82	8.78	11.7	15.3	19.6	24.4	30.4	54.3	85.1	18.3
65		0.589	0.945	1.36	2.00	2.66	4.38	6.28	9.28	12.3	16.1	20.7	25.7	31.9	56.6	88.6	18.9
70		0.628	1.01	1.44	2.12	2.82	4.63	6.64	9.79	13.0	16.9	21.7	26.9	33.4	59.0	91.0	19.5
75			1.07	1.53	2.25	2.98	4.88	7.00	10.2	13.7	17.7	22.7	28.2	34.8	61.4	95.0	20.1
80			1.13	1.62	2.37	3.14	5.13	7.36	10.7	14.4	18.6	23.8	29.5	36.3	63.7	99.0	208
85					2.50	3.30	5.38	7.72	11.2	15.0	19.4	24.7	30.8	37.8	66.1	102	214
90					2.62	3.46	5.63	8.08	11.7	15.7	20.2	25.8	32.1	39.3	68.5	106	220
95					2.75	3.52	5.98	8.44	12.2	16.4	21.0	26.8	33.3	40.8	70.8	11.0	22.6
100					2.87	3.77	6.13	8.80	12.7	17.0	2180	27.9	34.6	42.3	73.2	114	232
110						4.09	6.64	9.52	13.7	18.4	23.5	30.0	37.1	45.3	77.9	120	245
120							7.14	10.2	14.7	19.7	25.1	32.0	39.7	48.3	82.7	126	257
130							7.64	10.9	15.7	21.0	26.8	34.0	42.1	51.3	87.4	133	269
140							8.14	11.6	16.7	22.4	28.4	36.1	44.8	54.3	92.1	140	282
150							8.64	12.3	17.7	23.7	30.0	38.1	4730	57.2	96.9	147	294
160											31.6	40.2	49.8	60.2	101	154	306
170											33.2	42.2	52.3	63.2	106	161	318
180											34.8	44.2	54.8	66.2	111	168	331
190											36.4	46.2	57.3	69.2	116	174	343
200											38.0	48.4	59.8	72.2	121	181	356
