FULLY THREADED RODS

Approximate Weight in Kgs per Metre per Pc.

Size (MM)	Weight per Metre	Size (UNC)	Weight per Metre
M2	0.0187
M2.5	0.030
M3	0.044
M3.5	0.060
M4	0.078
M5	0.124
M6	0.177	¼”	0.194
M8	0.319	5/16”	0.323
M10	0.500	3/8”	0.469
		7/16”	0.650
M12	0.725	½”	0.896
M14	0.970	9/16”	1.096
M16	1.330	5/8”	1.342
M18	1.650
M20	2.080	¾”	2.021
M22	2.540	7/8”	2.756
M24	3.000	1”	3.638
M27	3.850	1 1/8”	4.545
M30	4.750	1 ¼”	5.718
M33	5.900	1 3/8”	6.842
M36	6.900	1 ½”	8.281
M39	8.200	1 5/8”	9.726
M42	9.400	1 ¾”	11.231
M45	11.000	1 7/8”	13.038
M48	12.400	2”	14.741

FULLY THREADED UNC (ASTM) STUDS

APPROXIMATE WEIGHT IN KGS PER NO.

Length	1/2"	5/8"	3/4"	7/8"	1"	1.1/8"	1.1/4"	1.3/8"	1.1/2"	1.5/8"	1.3/4"	1.7/8"	2"
50 mm	0.044	0.069	0.100	0.136	0.178	0.225	0.296	0.356	0.422	0.493	0.570	0.681	0.771
55 mm	0.049	0.076	0.110	0.150	0.195	0.247	0.326	0.392	0.464	0.543	0.627	0.749	0.848
60 mm	0.053	0.083	0.120	0.163	0.213	0.270	0.355	0.428	0.506	0.592	0.684	0.817	0.925
65 mm	0.058	0.090	0.130	0.177	0.231	0.292	0.385	0.463	0.549	0.641	0.741	0.885	1.002
70 mm	0.062	0.097	0.140	0.190	0.249	0.315	0.415	0.499	0.591	0.690	0.798	0.953	1.079
75 mm	0.067	0.104	0.150	0.204	0.266	0.337	0.444	0.535	0.633	0.740	0.855	1.021	1.156
80 mm	0.071	0.111	0.160	0.218	0.284	0.360	0.474	0.570	0.675	0.789	0.912	1.089	1.233
85 mm	0.075	0.118	0.170	0.231	0.302	0.382	0.504	0.606	0.717	0.838	0.969	1.158	1.310
90 mm	0.080	0.125	0.180	0.245	0.320	0.404	0.533	0.641	0.760	0.888	1.026	1.226	1.387
95 mm	0.084	0.132	0.190	0.258	0.337	0.427	0.563	0.677	0.802	0.937	1.083	1.294	1.464
100 mm	0.089	0.139	0.200	0.272	0.355	0.449	0.592	0.713	0.844	0.986	1.140	1.362	1.541
110 mm	0.098	0.153	0.220	0.299	0.391	0.494	0.652	0.784	0.928	1.085	1.254	1.498	1.695
120 mm	0.107	0.166	0.240	0.326	0.426	0.539	0.711	0.855	1.013	1.184	1.388	1.634	1.850
125 mm	0.111	0.173	0.250	0.340	0.444	0.562	0.741	0.891	1.055	1.233	1.425	1.702	1.927
130 mm	0.115	0.180	0.260	0.353	0.462	0.584	0.770	0.926	1.097	1.282	1.482	1.770	2.004
140 mm	0.124	0.194	0.280	0.381	0.497	0.628	0.829	0.998	1.182	1.381	1.596	1.907	2.158
150 mm	0.133	0.208	0.300	0.408	0.533	0.674	0.889	1.069	1.266	1.480	1.710	2.043	2.312
160 mm	0.142	0.222	0.320	0.435	0.568	0.719	0.948	1.140	1.350	1.578	1.824	2.179	2.466
170 mm	0.151	0.236	0.340	0.462	0.604	0.764	1.007	1.212	1.435	1.677	1.938	2.315	2.620
175 mm	0.155	0.243	0.350	0.476	0.621	0.786	1.037	1.247	1.477	1.726	1.995	2.383	2.697
180 mm	0.160	0.250	0.360	0.489	0.639	0.809	1.066	1.283	1.519	1.776	2.052	2.451	2.774
190 mm	0.169	0.264	0.380	0.517	0.675	0.854	1.126	1.354	1.604	1.874	2.166	2.588	2.928
200 mm	0.178	0.277	0.399	0.544	0.710	0.899	1.185	1.425	1.688	1.973	2.280	2.724	3.083
210 mm	0.186	0.291	0.419	0.571	0.746	0.944	1.244	1.497	1.772	2.071	2.394	2.860	3.237
220 mm	0.195	0.305	0.439	0.596	0.781	0.989	1.303	1.568	1.857	2.170	2.508	2.996	3.391
225 mm	0.200	0.312	0.449	0.612	0.799	1.011	1.333	1.604	1.899	2.219	2.565	3.064	3.468
230 mm	0.204	0.319	0.459	0.625	0.817	1.034	1.363	1.639	1.941	2.269	2.622	3.132	3.545
240 mm	0.213	0.333	0.479	0.653	0.852	1.079	1.422	1.710	2.026	2.367	2.736	3.268	3.699
250 mm	0.222	0.347	0.499	0.680	0.888	1.124	1.481	1.782	2.110	2.466	2.850	3.405	3.853
260 mm	0.231	0.361	0.519	0.707	0.923	1.169	1.540	1.853	2.194	2.565	2.964	3.541	4.007
270 mm	0.240	0.375	0.539	0.734	0.959	1.213	1.600	1.924	2.279	2.663	3.078	3.677	4.161
275 mm	0.244	0.382	0.549	0.748	0.977	1.236	1.629	1.960	2.321	2.713	3.135	3.745	4.238
280 mm	0.249	0.388	0.559	0.761	0.994	1.258	1.659	1.995	2.363	2.762	3.192	3.813	4.316
290 mm	0.257	0.402	0.579	0.788	1.030	1.303	1.718	2.067	2.448	2.861	3.306	3.949	4.470
300 mm	0.266	0.416	0.599	0.816	1.065	1.348	1.777	2.138	2.532	2.959	3.420	4.086	4.624
